With its broad range of measurement accessories, the new Multimar 25 EWR Digital Universal Caliper from Mahr Federal is a versatile and configurable caliper for I.D. and O.D. measurement requirements. Available in four capacities with outside measuring ranges up to 1,250 mm (50"), the 25 EWR is designed for measuring outside and inside dimensions, narrow collars, external and internal tapers, dovetails, grooves, distances between hole centers, centering shoulders, scribing workpieces and more.
"Unlike standard calipers, both measuring arms of the 25 EWR can be moved along the beam, thus functioning like a beam-gauge, and providing well-balanced weight distribution even with small dimensions," said a company spokesperson. The application range can be extended by reversing the interchangeable measuring arms. Plus, the digital display is always in the operator's line of vision due to the patented mounting fixture of the measuring arms and attachments provided.
What makes the Multimar 25 EWR so versatile is the wide range of measuring arms, anvils, mounting attachments and depth stops, which can be configured by the user. Anvils and tips are available in a variety of shapes and configurations, including threads, flat and spherical shoulders, blades and round faces. Depth stops can be set to the exact measuring depth in the horizontal measurement position to provide precise support on the reference plane surface. This improves repetitive accuracy when conducting comparison measurements in the second axis, and when used with a rectangular gauge block, can provide accurate depth measurement on cones.
Data output is via USB, Digimatic, Opto RS232C or wireless, and battery life is about three years. The Multimar 25 EWR Universal Caliper provides IP 65 protection for all workshop conditions, and is supplied with battery, instruction manual, hardwood mounting and resting blocks and a finely crafted wooden case.
For more information contact:
Mahr Federal Inc.
1144 Eddy Street
Providence, RI 02905
800-343-2050 / 401-784-3100
information@mahr.com
www.mahr.com
