Interchangeable Vise Jaws and Clamping Jaws



IMR Environmental Equipment Development LLC has introduced its interchangeable vise jaws and RIGO elements clamping jaws.

Rectangular workpieces are automatically centered and aligned in two directions with RIGO elements clamping jaws. Rectangular workpieces up to a ratio of 1:3 are automatically centered and aligned in all directions with the interchangeable vise jaws.

The RIGO interchangeable vise jaws are suitable for repetitive machining due to the ability to accurately position workpieces. The constant clamping accuracy also results in decreased scrap rates.

The RIGO interchangeable vise jaws are available in 16MnCr5, which is case hardened and polished. Special models with custom dimensions are also available.

The RIGO clamping jaws provide for fast, easy and safe clamping due to the Double Vee block surface. They are designed to save time, increase accuracy and reduce possible errors during clamping and alignment of workpieces. Concentricity and lateral guiding accuracy is less than 0.02 mm with the RIGO clamping jaws.

With the clamping jaws, workpieces can be machined on five sides. They are suitable for applications in NC and special mechanical engineering.

The RIGO elements are available in two versions for a variety of applications: Type A, an insert element; and Type B, an adapter element. Customized variants can be delivered upon request.

For more information contact:

IMR Environmental Equipment, Inc.

3634 Central Ave.

St. Petersburg, FL 33711

800-746-4467 / 727-851-9922

imrllc@yahoo.com

www.imrusa.com

www.imrusa.com/website/english/Rigo.html
