CAD/CAM Software Offers Increased Design Flexibility



Tebis new Version 4.0 Release 3 CAD/CAM software will be featured in Booth 737 at AeroDef 2017.

Tebis America, a software company specializing in CAD/CAM systems for design and manufacturing for the tool, die, mold, aerospace and defense manufacturing industries, will feature its newest version 4.0 Release 3 software in Booth 737.

Highlights of the new launch include: toolbars and menu panels that can be easily docked to the edge of the application window; software interface that allows a user to learn to operate it more quickly and easily and with less effort; and a new project dialog with the most recently used files displayed immediately after the program is started.

With Version 4.0 Release 3, Tebis has also improved the display of wire frame models and isolines. Further, Tebis has focused on a more efficient use of time by automatically breaking up assemblies and complex files into multiple individual files.

Another timesaving benefit is optimized reverse engineering. Release 3 provides improved algorithms that generate transitions for four-edged surfaces.

In surface modeling, when generating surfaces with constant curvature, Release 3 supports symmetrical areas and provides better management of input parameters when using optimization functions.

The user can shorten cycle times by roughly 30% in laser cutting and trimming because the improved NC point distribution results in more compact programs. The user can set axial tolerances and manually remove NC points.

To meet the demands of the manufacturing industry, the company offers multiple industry-specific bundles, all with the intent to fit the size and ability of a user. These scalable levels are intended to create an exact fit for a manufacturer's CAD/CAM/NC process chain.

The Standard version is an entry solution designed to fit most shops. "Companies that have standard 3-axis NC milling machines and utilize low-end CAD/CAM products will be able to acquire the power of Tebis at similar pricing," said a company spokesperson.

The Pro version is designed for mid-sized companies that are utilizing multi-axis machines and demand a higher level of automation for their operation.

"The Premium package delivers the complete solution package, making the highest automation and highest strategies available," said the spokesperson.

For more information contact:

Tebis America

400 E. Big Beaver Rd.

Troy, MI 48083

248-524-0430

info@tebisusa.com

www.tebis.com

AeroDef 2017 Booth 737
