According to 5ME, its CYCLO COOL 900 series synthetic metal machining fluids utilize a near-neutral pH formula developed to meet heavy-duty, high-heat machining requirements at a lower cost than semi-synthetics and soluble oils. The additive-free, low-foaming fluids are formulated for machining titanium, Inconel, beryllium copper, hardened steels, stainless steels and other exotic alloys. The cationic-based synthetic coolants contain boundary lubricants designed to penetrate the cut zone heat barrier, even at lower fluid pressures (300 to 400 PSI), to absorb heat from the tool and the part, minimizing tool-tip work hardening and premature wear. "Free of biocides/fungicides and aggressive pH adjusters, they provide increased sump life and environmental friendliness when replacing high-maintenance, chlorinated, semi-synthetics and soluble oils in all metal removal operations. These high-performance, low-cost traits are driving efficiency improvements in the aerospace and heavy equipment industries," said Pete Tecos, Executive VP Marketing and Product Strategy for 5ME.
CYCLO COOL 900 series fluids are designed for high-pressure, low foaming, through-tool delivery systems at 2,000 PSI, as well as flood coolant for chip flushing. The lubrication package in CYCLO COOL 900 varies to cover a range of applications from light-duty, high-speed (10,000 to 15,000 RPM) aluminum milling to heavy-duty drilling and tapping of hardened steel and hard-to-machine metals. The three formulations, CYCLO COOL 900, 910, and 920 are engineered to match the intensity of the application.
5ME recently completed a facility-wide turnkey project consisting of onsite CNC programming, application support, fixturing concepts and tooling packages for machining large steel frames for above ground mining equipment. The project involved implementation of CYCLO COOL 920 throughout the facility. "The most critical application was a proprietary, specialized tapping process to lock bolts into a massive steel frame," said Tecos. "This tapping process is critical to efficient production and, if not completed correctly, the entire frame must be scrapped."
"CYCLO COOL 920 not only met and exceeded the tight-finish tapping requirement, it is also credited with increasing tap life to 1,000 hits per tap, compared to the same process using a premium, heavy-duty soluble oil. CYCLO COOL 920 also met the plant's corporate health and safety requirements, which include minimal-to-zero VOC levels, recyclability and elimination of questionable raw materials and aggressive biocides/sump additives. The near neutral pH synthetic formulation provides a clean, oil-free work area and is extremely operator and machine friendly," said Tecos.
For more information contact:
5ME
4270 Ivy Pointe Blvd.
Suite 100
Cincinnati, OH 45245
513-719-1600
www.5me.com
