Torque Motor Rotary Tables

HIWIN Corporation will feature families of precision motion control components with the (TMRT) as a highlight of the booth.

Designed for machine tool OEMs and retrofitters, the TMRT series enables 3-axis machine tools to be readily upgraded to 3+1, 3+2, 4+1 or even 5-axis capability. "High speed, high torque, built-in high-rigidity high-precision bearings, absolute encoders and a powerful brake system ensure excellent acceleration capabilities and high precision when machining complex part geometries," said a company spokesperson.

HIWIN's TMRT series rotary tables incorporate direct-drive torque motors. This design eliminates any gear reducers, resulting in high dynamic performance and multiaxis path accuracy. Directly coupled encoders and zero backlash enable tighter part tolerance. Direct drives provide smooth motion, resulting in improved part surface finish.

"The TMRT series incorporates integral liquid cooling in the table, offering thermal stability even during high duty cycle, high load conditions, yielding consistent part quality," said the spokesperson.

The TMRT series is compatible with most major CNC brands, making control integration straightforward.

HIWIN TMRTs utilize HIWIN's torque motor components, which are also available for engineers who prefer to design and build a unique table.

For more information contact:

Andy Choi, Product Specialist

HIWIN Corporation

12455 Jim Dahmer Road

Huntley, IL 60142


IMTS East building, Level 3

Booth 134514
