Laser Alignment Systems

Hamar Laser will showcase its versatile next-generation L-703 Bore & Spindle Alignment Laser System and its enhanced L-702SP 5-Axis Machine Tool & Spindle Alignment System at IMTS.

"After several rounds of designs to meet our goals of lower cost and a more compact form factor, we have been very pleased with how many different applications the new L-703 can meet," said Rod Hamar, President of Hamar Laser Instruments. "We are rolling out several new L-703 system packages that we are excited to show at IMTS."

"Combining our L-703 and L-702SP lasers with our recently introduced wireless T-1296 Hi-Resolution 5-Axis Multi-Purpose Scan & Spindle Targets has led to an increase in accuracy and performance, while maintaining the ease of use our lasers are known for," continued Hamar.

"In today's climate of rising prices," added Hamar, "we are pleased to offer these systems at a lower price-point, which should be attractive to shops looking for an affordable, accurate and faster way to check alignments for PMs or after machine crashes."

Hamar Laser's IMTS 2022 lineup will include:

• Multiturn Alignment-Hamar Laser packaged its versatile L-702SP 5-Axis Machine Tool & Spindle Alignment System with its new T-1296 Targets to create a compact, streamlined laser alignment system to quickly and accurately align a wide variety of machine tools, from complicated multiturns to lathes and machining centers. In addition to flatness, straightness and squareness, the L-702SP also measures axis pitch and yaw angular errors.
• Lathe Alignment-Hamar's new L-703S 4-Axis Lathe & Turning-Center Spindle Alignment Laser System features an accurate laser that streamlines checking and adjusting the alignment of lathes and turning centers. "With a range of up to 50 ft. (15 m), the L-703S can check the largest lathes, where traditional methods are hard to use. It can also quickly check spindle alignment of headstocks to tailstocks or sub-spindles in four axes," said a company spokesperson.
• "Bore Alignment-Hamar Laser's new L-703B Self-Centering Bore Alignment System makes bore alignment easier and up to 75% faster than competing systems," said the spokesperson. Smaller and lighter than the L-705 it replaces, the L-703B works with Hamar's patented self-centering targets that require only one measurement per bore. Hamar's new L-112 Laser Mounting Stand has a built-in position control to speed up laser set-ups. Applications include engine blocks, compressor bores, cylinders, shaft bearing bores, stern tubes and many others.

Hamar Laser will also exhibit its recently introduced L-703B Twin-Barrel Extruder Alignment System and its rebranded X-Series of advanced shaft alignment products (formerly Stealth Series).

Hamar Laser will be exhibiting in the Quality Assurance pavilion and is also hosting a Virtual Showroom.

For more information contact:

Hamar Laser

5 Ye Olde Road

Danbury, CT 06810

203-730-4600

sales@hamarlaser.com

www.hamarlaser.com

IMTS East Building, Level 3

Booth 135427
