Lead Screw Configurator



igus offers a lead screw configurator designed to allow customers to quickly design their own lead screw and associated drawing without in-depth technical knowledge and CAD software.

"Designing a lead screw usually requires significant effort for the user, who is required to have technical drawing skills and access to a CAD program," said a company spokesperson.

The new online system from igus allows designers to configure a long-lasting lead screw in minutes.

Trapezoidal, high helix or metric thread lead screws, in combination with nuts made of iglide high-performance polymers, allow lubrication-free adjustment for long-lasting and smooth-running applications.

The new tool for igus directly checks the plausibility of the configuration. This way, anyone can become a designer without any CAD software. In three steps, the user can customize a lead screw, configure the machined end and directly generate a dimensional drawing. The designer can download the 3D model of the configuration and order the pre-configured lead screw or request a binding offer.

The three-step configuration process starts when the customer determines the type of lead screw. In addition to the classic trapezoidal thread and the metric thread, the user also has the option of choosing the dryspin high helix thread. This is a thread patented by igus, which offers a higher efficiency through an optimized flank angle. After selecting the thread type, the user determines the thread direction, the material and the lead screw strength.

In the second step, the machined ends are configured. The configuration offers the user the opportunity to design the base body from outside inwards, and add 12 standard elements such as chamfer, champing surface or circlip to the machined end.

In the configuration process, the designer can download the current dimension drawing directly at any time. The price of the lead screw is displayed, so the user sees price adjustments during the configuration process.

In the final step, the customer receives a complete overview of the configuration. The designer can download the STEP file for further construction of the application, save the configuration as a link for follow-up orders or share it with colleagues. With a simple click, the fully configured lead screw can be ordered online. The order is automatically transmitted to the igus factory, where processing starts within 30 minutes.

For more information contact:

igus, Inc.

P.O. Box 14349

East Providence, RI 02914

800-521-2747

sales@igus.com

www.igus.eu/leadscrew-configurator
