Dimensional Measurement Solutions on Display
April 1, 2016
Mahr Federal will feature the MarShaft SCOPE 250 plus, a new addition to its growing family of optical shaft measurement systems at, Mfg4.
Mahr Federal will feature the MarShaft SCOPE 250 plus and MarCator Wireless Digital Indicators at Mfg4.
The MarShaft SCOPE 250 plus features an accurate matrix camera with 4 million pixels. The system measures parts up to 250 mm in length and 40 mm in diameter with accuracy. "A maximum permissible error (MPE) of less than 1.5 µm + L/40 when measuring diameter and 3 µm + L/125 when measuring length is more accurate than other systems using line cameras," said a company spokesperson.
Also featured will be Mahr Federal's line of mechanical comparative gauges, which can be configured for wireless data transmission with the addition of a MarCator 1086 or 1087 wireless digital indicator. The line includes a wide array of snap gauges, I.D. and O.D. gauges, fixed and adjustable bore gauges, as well as depth and comparator stands. The addition of wireless digital indicators makes these gauges faster and more productive.
"The combination of Mahr Federal's high performance comparative gauges with an economical, user-transparent wireless data collection system provides a way to upgrade and implement data collection for existing gauges or new gauging requirements. The delays and errors associated with manually collecting and recording data are eliminated, and the measuring process can run at its maximum speed and with the most secure collection format," said the spokesperson.
Also on display at Mahr Federal's booth will be:
- MarVision QM 300, a new video measuring microscope with image processing capability designed for the measurement and/or dimensioning of geometric elements.
- Millimar C1200 Digital Amplifier>
- MaraMeter mechanical comparative gauges
- Wireless MarCal calipers with Marcom Software
- Dimensionair air gauging
- Selections from Mahr Federal's line of surface measuring instruments, including both portable roughness measurement devices and computer based stationary surface measuring systems. In addition to the new PocketSurf IV, there will be the MarSurf PS1 and a growing line of application specific surface measuring fixtures. Mahr's stationary system line includes the MarSurf XR 1, which combines mobile surface metrology with the MarWin evaluation software, and the XCR 20 MarWin, a new generation of combined roughness and contour measurement systems.
- A full range of Mahr Federal handheld gauges and other dimensional metrology products.
For more information contact:
Mahr Federal Inc.
1144 Eddy Street
Providence, RI 02905
800-343-2050 / 401-784-3100
information@mahr.com
www.mahr.com
Mfg4 Booth 1605
