Automated Metrology and Force Measurement



The L.S. Starrett Company will be featuring the automated inspection capabilities of its metrology and force measurement systems, and will also highlight custom gauging solutions at EASTEC booth 3244.

"Starrett video-based measurement systems combine high-resolution images, powerful intuitive software and precision mechanical platforms to deliver superb accuracy and repeatable measurement results," said a company spokesperson. "Automatic edge detection or video edge detection locates edges of parts being measured, enabling go/no-go comparisons to an engineering design, with no need for Mylar overlays. This dramatically increases measurement throughput while eliminating operator subjectivity."

Starrett will demonstrate pattern recognition and automated inspection on several metrology systems at EASTEC, including:

  • Recently enhanced AVR300 Multi-Sensor Vision System, featuring the largest field of view (FOV) to date for Starrett and suited for repetitive measurements and automatic comparison to CAD files.
  • HDV Horizontal Digital Video Comparator, which combines the best features of vision and optical comparator technology.
  • HD400 Horizontal Dual Lens Comparator offering a two-lens mount, enabling instant switching between two magnification lenses or video camera adapter.

Starrett will also showcase its Force Testing Systems, highlighting the flexible architecture that enables the range of Starrett force and material testing software programs to be compatible with its different test frames. At EASTEC, Starrett will demonstrate its FMS Series test frame featuring a new Long-Range Extensometer that is used to calculate elongation based on the overall distance moved. This easy-to-use fixture provides a long travel distance, critical for rubber and elastomer applications. Also, the Starrett FMM Computer-Based Force Testing Solution, which is compact and designed for high volume, lean manufacturing production, will be featured. Starrett L1 software, engineered for quality control and incoming inspection and designed to meet the requirements for efficient high-volume production testing, will be demonstrated on the FMM frame.

Starrett DFC Digital Handheld Force Gages will also be featured. The DFC may be used as an advanced digital force gauge and controller with Starrett FMM Force Testers and can serve as a universal interface.

Starrett Special Custom Gaging solutions and capabilities will also be showcased at EASTEC. "Even with the availability of hundreds of standard precision tools and gauges, sometimes measuring challenges are best solved with a specially made gauge," said the spokesperson. "The Starrett Special Gage Division designs and builds dimensional measuring instruments for a wide range of industries that provide guaranteed performance to meet customer specifications."

For more information contact:

The L.S. Starrett Company

121 Crescent St.

Athol, MA 01331

978-249-3551

sales@starrett.com

www.starrett.com

EASTEC Booth 3244
