Compact Material Handling System

Bystronic offers its larger format 4020 (6' x 12' material size) ByTrans Extended compact material handling system. "This system yields greater profits through higher machine utilization, process efficiency, expanded operations and reduced labor costs. Loading and unloading of materials takes just 75 seconds so that the system is always faster than the shortest cutting plan. The short cycle time, which is independent of the thickness of the metal sheet, provides greater overall throughput," said a company spokesperson.

ByTrans Extended offers complete accessibility and optimum operation in a small, inline footprint and handles all sheet thickness up to 3/4" plate. Available with two raw material locations and one unload location, the second raw material location can also serve as the location for the unloading of automatically sorted parts.

The ByTrans Extended is designed with two cassettes, thereby making the machine system more autonomous. The system offers flexible use - not just for storage/return transfer but also for large parts removal as well as the preparation of plastic protective separators, which are placed between the metal sheets by the system. An additional benefit is entry into lightly-manned parts production.

For more information contact:

Bystronic Inc.

200 Airport Road

Elgin, IL 60123

847-214-0300 / 800-247-3332
