Jet Edge recently released a new brochure highlighting its precision waterjet pumps. Featuring Jet Edge's 90KSI X-Stream and 60KSI Dominator Series hydraulic intensifier pumps and Eco-Jet direct drive pumps, the brochure provides an overview of Jet Edge's ultra-high pressure pump technology for precision waterjet cutting, as well as a side-by-side comparison of the two pump styles.
Jet Edge Hydraulic Intensifier Pumps
Jet Edge's Dominator and X-Stream Series hydraulic intensifier pumps are available in a range of sizes from 30 - 200 HP and are capable of producing pressures from 60,000 - 90,000 PSI and flow rates of 0.6 - 4 GPM for waterjet cutting and surface preparation applications. The pumps feature a tie-rod design intended to eliminate threads on the high-pressure cylinders, end caps and hydraulic cylinders, reducing the likelihood of cracking and increasing component life. Matched-metal components help prevent galling of hydraulic components. Jet Edge intensifier pumps also feature patented Metal-on-Metal seal technology that cuts in half the number of seals needing to be replaced, reducing downtime for seal changes, according to the company.
Hydraulic accumulators are standard on all Jet Edge waterjet intensifier pumps. This provides smoother hydraulic pressure, reduces spikes and prolongs hydraulic pump life. Hydraulic fluid is cooled and filtered, and a hydraulic center section incorporates high-duty cycle-rated piston seal and wear rings. Jet Edge's hydraulic systems have a 4,000 hour warranty. Jet Edge waterjet pumps also feature CE marked attenuators that smooth pressure fluctuations and deliver a constant and steady stream of ultra-high pressure water to the cutting tool, helping ensure optimal cut quality.
Jet Edge Eco-Jet Direct Drive Pumps
Jet Edge's Eco-Jet direct drive positive displacement water jet pump produces 55,000 PSI (3,800 bar) ultra-high pressure water for precision waterjet cutting and surface preparation applications, and supports a .015" (.38 mm) orifice. "Eco-Jet pumps feature independent attenuators that smooth pressure fluctuations, increasing cutting speeds and extending component life," said a company spokesperson.
The Eco-Jet is available in three configurations, standard, PTO and TACH. The standard Eco-JET features a 30 HP (22 kW) electric motor that, according to the company, uses up to 50% less electricity than a 50 HP hydraulic intensifier pump, but produces the same output. The Eco-Jet PTO utilizes a tractor PTO shaft to drive the plunger pump rather than an electric motor. The Eco-Jet PTO is available for 540 RPM and 1,000 RPM PTO shafts and Category 1 and 2 three point hitches (tractor sold separately). The Eco-Jet TACH uses a tractor or skid steer's hydraulic circuit to drive the plunger pump rather than an electric motor. It is available for hydraulic circuit units capable of producing a minimum of 50 HP. Maximum pressure is dependent on the tractor's hydraulic fluid flow and pressure. "Unlike traditional industrial waterjet pumps, the Eco-Jet PTO and Eco-Jet TACH require only a standard 120 V 60 Hz power source and fresh water source, making them practical for rural machine shops and shops with a limited power supply," said a company spokesperson.
