MC Machinery Now Offering 2-D and 3-D Machine Inspection Systems



MC Machinery Systems Inc., a subsidiary of Mitsubishi Corp., has partnered with InspecVision Planar US and will be offering the next generation of precision metrology. InspecVision, the high speed integrated 2-D and 3-D measurement system, brings speed, accuracy and reliability to a shop's measurement quality process.

InspecVision Planar 2D can be used to quickly measure or reverse engineer flat parts that have been manufactured on laser, plasma and waterjet cutting systems as well as punched and some stamped parts. Planar customers range from small job shops to multibillion-dollar turnover companies covering almost every industry that uses sheet metal, such as electronics and communication industries, automotive and aerospace.

The InspecVision Opti-Scan 3D uses a high-speed, high-resolution industrial camera and an LED DLP projector to scan the surfaces of an object. Patterns of light are beamed from the projector onto the part, and these patterns are recorded by the camera and used to create surface measurements.

This system also features a back-light table to capture the silhouette of a part. This silhouette image is then converted into 3-D edge measurements using the patented Planar Edge 3DTM technology. 3-D edges are essential when measuring the critical features of sheet metal parts, including the hole size and position, which are defined by the part's edges, not its surfaces.

Available in a range of sizes and accuracies, the InspecVision systems can be installed on the factory floor and are easy for staff to operate, helping to cut expensive inspection bottlenecks.

For more information contact:

MC Machinery Systems, Inc.

85 Northwest Point Blvd.

Elk Grove Village, IL 60007

630-616-5920

sales@mcmachinery.com

www.mcmachinery.com
