SV-Point Spade Drill Inserts
April 1, 2020
"YG-1 SV-Point spade drill inserts are designed for longer tool life at higher spindle speeds and feeds than conventional spade drills," said a company spokesperson. "SV-Point spade drill inserts offer exceptional performance in a wide range of applications and materials including steel, stainless steel and cast iron."
Features include:
- H-coating for high heat and wear resistance
- Sinusoidal thinning edge for smooth cutting and improved centering
- Positive rake angle for improved hole finish
- Low thrust force-providing an option for underpowered machines.
Three material options are available. "Super Cobalt (T15) is designed to provide improved tool life and performance over standard HSS inserts," said the spokesperson. Size range is 9.5 mm to 114.3 mm.
Premium Cobalt (M48) is engineered to extended tool life over T15 in harder materials. Size range is 9.5 mm to 114.3 mm.
Carbide C5 (P40) is designed for longer tool life and faster speeds and feeds in rigid set-ups. Size range is 9.5 mm to 47.6 mm.
For more information contact:
YG-1 Tool Co.
730 Corporate Woods Parkway
Vernon Hills, IL 60061
800-765-8665
heatherlee@yg1usa.com
www.yg1usa.com
