Made in Kentucky, the Mazak QUICK TURN UNIVERSAL (QTU) 350MY turning center, while simple in its design, has qualities that enhance efficiency and accuracy for high-volume small parts production.
Designed for the automotive, consumer electronics, contract manufacturing and medical industries, the QTU 350MY has a 20 HP, 3,500 RPM turning spindle, a milling turret with a rotary tool spindle for multitasking operations and Y-axis functionality that offers machining above and below centerline.
The machine's integral spindle/motor headstock provides rigidity in heavy-duty machining and precision in high-speed applications. A variable-speed AC powers the headstock so there is zero blacklash. A full-circumference C-axis headstock brake design provides high-accuracy positioning within 0.0001°.
The servo-driven turret on the QTU 350MY offers multiple tool configurations for easy changeover. It features a roller gear cam drive system that helps ensure smooth high-speed, high-accuracy indexing motion. The roller gear design eliminates the need for expensive components, such as curvic/index couplings. Without couplings, the turret can include up to 24 small tools as well as program an infinite number of index positions without having to make any changes on the turret housing.
The QTU 350MY has a maximum swing of 27.4" and can accommodate parts up to 13.5" in diameter and 19.6" long. It also has a bed design with a low center of gravity for rigid heavy cutting performance. A one-piece way cover helps simplify chip disposal.
The machine can integrate with various forms of automation, including bar feeders, gantry loaders and robots, to achieve higher levels of productivity.
