Suhner has introduced a new and re-designed version of its BEX15 machining unit, capable of a spindle speed increase from 18,000 RPM to 23,000 RPM.
"Chip producing machining operations with modern tools today demand progressively higher cutting speeds, specifically for metals with high cutting speed rates or small diameter hole drilling applications," said a company spokesperson. "The Suhner machining unit type BEX15, proven in thousands of installations, now provides new speed options reliably up to the maximum speed limit. With an increase of 25% up to a permissible maximum spindle speed of 23,000 RPM, operations requiring higher spindle speeds can be accomplished more easily."
This improvement is the result of a complete redesign of drive and spindle bearing components. A new style timing belt drive multiplies the motor speed up to 13,050 RPM spindle speed. An AC inverter drive is used to increase the spindle speed up to 23,000 RPM at 87 Hz.
The machining unit BEX15 can be applied in axial and radial orientation, directly mounted to a Suhner slide assembly type UA15-PH or UA15-CNC. In this combination, a variety of machining operations, such as milling or demanding drilling cycles, including jump or peck feed, can be accomplished.
"Four optional toolholder systems (collet ER25, ISO30, HSK50 and Weldon), standard air purge connections for spindle and belt housing, including a number of additional options (for example: coolant through the spindle or automated tool change features), make this machining unit type BEX15 highly adaptable and an optimal choice for demanding and specific machining requirements," said the spokesperson.
