Cageless and High Peak Torque Motors
July 1, 2014
ETEL now offers cageless and high peak torque motors - called the TML and TMM series - within its line of motor technologies.
"When an application does not require a motor to be in a caged structure, the TML and TMM motors are lighter, lower cost alternatives to ETEL's better known TMB model, yet still provide a direct drive technology option. Mounting is easy with both series as the TML has the lugs located along its outer diameter which provide a simple mounting method contributing to its lower cost. The TMM is even lighter and is designed to be directly glued into the machine structure," said a company spokesperson.
The TML/TMM motor series is an option for applications that have less demanding continuous torque requirements. Despite this, they are able to provide the same peak torque as the TMB range with up to 5,000 Nm and reach speeds of up to 2,100 RPM. The TML/TMM both come in multiple standard sizes which vary in diameter, length and power. Also, each model offers different types of coil winding providing more performance variations.
The TML/TMM motors are designed specifically for direct drive applications and as such feature the following:
- Fewer parts requiring lower overall costs.
- Stable performance all along machine lifetime due to zero maintenance required on the motors.
- No backlash, allowing for better accuracy and repeatability.
- Smooth, precise and efficient motions.
- Compact design.
It is an ETEL standard for all data sheets to list specifications at an ambient temperature of 20 °C (68 °F) and to be listed at the motor's maximum allowable temperature to ensure the user is able to utilize every bit of power that the motor offers.
ETEL S.A. is a supplier of direct drive and motion control components and integrated systems. The company supports high tech industry with linear motors, torque motors, positioning stages, and motion controllers/systems.
For more information contact:
HEIDENHAIN Corporation
333 E. State Parkway
Schaumburg, IL 60173-5337
847-490-1191
info@heidenhain.com
www.heidenhain.us
ETEL S.A.
Zone Industrielle
CH-2112 Motiers
Switzerland
+41 (0)32-862-0100
www.etelusa.com
