Dynamic Machining Centers for Complex Workpieces



CHIRON offers a brochure featuring its 16 Series of dynamic, highly precise machining centers for high-performance and productive machining of complex workpieces.

The new CHIRON FZ16 S is a single spindle 5-axis while the DZ16 W features a double spindle with workpiece changing device for high volume production.

FZ16 S features:

  • XYZ travels (max.): 660 mm x 660 mm x 400 mm
  • Power (max.): 61 kW
  • Spindle speed (max.): 20,000 RPM
  • Torque (max.): 200 Nm
  • Chip-to-chip time: from 2.2 s
  • Number of tools (max.): 162.

DZ16 W features:

  • XYZ travels (max.): 340 mm x 450 mm x 400 mm
  • Power (max.): 61 kW
  • Spindle/distance DZ: 2/320 mm
  • Spindle speed (max.): 20,000 RPM
  • Torque (max.): 200 Nm
  • Chip-to-chip time: from 2.4 s
  • Rapid feed max.: 75 m/min
  • Number of tools (max.): 2 x 80
  • Automatic workpiece change: from 3.5 s.

For more information contact:

CHIRON America, Inc.

10950 Withers Cove Park Drive

Charlotte, NC 28278

704-587-9526

info@chironamerica.com

www.chironamerica.com
