Pipe Profiler and RoboRail Robotic Plasma Cutting Machine

HGG Profiling Equipment BV will be exhibiting its ProCutter 900 RB Pipe Profiler in booth B13051 at FABTECH 2023. The recently introduced RoboRail robotic plasma cutting machine will be featured in partner Automated Layout Technology's booth A5716.

The ProCutter 900 RB integrates the proprietary ProCam software for 3D parameter-based part profile programming for perfect fit-up. A three-jaw chuck offers secure pipe positioning and durable pipe support, while a cutting bed equipped with a roller bed offers easy pipe loading and unloading. Available with a cutting trolly with biaxial cutting head for efficient oxy-fuel plasma cutting, the system's easy-to-use operator interface with touchscreen navigation simplifies the training process.

The RoboRail is engineered to reduce profile cutting time by up to six hours in some applications, including pipe for railings, channels and other miscellaneous parts. The compact robotic machine's ability to take designs directly from 3D SDS/2, TEKLA, STEP and other CAD files allows accurate cutting performance for channels, tube columns and angles up to 8" x 8" and 1-1/4" pipe. The Hypertherm plasma cutting system processes handrail pipe, stringer channels, box tubes, angles, etc.

At the show, HGG will feature the Imperial measurement version of the RoboRail system, which features an infeed length/weight up to 882 lbs. and outfeed length up to 8' maximum with an outside diameter of 10.79" and minimal flat bar thickness of 0.40". One customer reduced pipe profile cutting time from several minutes manually to 30 seconds after adopting the automated RoboRail system, including layout and marking. The system's cutting accuracy eliminates the need for grinding and sawing and shaves significant time off welding processes. Visitors to the booth will be able to speak with automated 3D plasma cutting experts who will be available to discuss additional automated 3D profile cutting systems suitable for a wide variety of industries.

Represented exclusively in the U.S. by Automated Layout Technology, RoboRail is suitable for supplementing larger capacity machines for added processing flexibility to cut copes and cut-outs quickly and accurately in angle, single-story tube columns for strip malls or mezzanines, bolted stairs and 8" or 10" structural pipe.

For more information contact:

HGG Profiling Equipment BV


FABTECH Booth B13051

Automated Layout Technology

3 Christine Drive

Hudson, NH 03051


FABTECH Booth A5716
