Brochure on High Power Modular AC Drives
December 1, 2016
Parker Hannifin offers a brochure on the AC890PX High Power Modular AC Drives. The drives are powered from 150 to 600 HP at 110 - 400 kW.
The building block drive includes a PowerPak module that plugs into a common bus rail system to form a complete drive. The enclosure, disconnect, line reactor and fusing are included.
Plug-in Modularity Includes
- Sealed modules are easy to install and service
- Modules replace in minutes
- Easy-to-handle under 50 lbs.
- Replaceable by local technical staff
- Freight friendly, easily shipped around the globe
- Packaged and designed to clear customs quickly.
The integrated bus system includes minimized power wiring and keyed modules to reduce errors.
The compact size saves factory floor space and is only 20" wide. The drive has built-in torque braking, four-quadrant dynamic response and a braking resistor that is duty-cycle limited.
Each PowerPak Module bay holds one Powerpak module. It includes inverter phase assemblies, DC supplies and capacitor modules. Bus bars run across the PowerPak module back with self-aligning, silver-plated pluggable connectors. Cooling fans draw air in the front and out a top plenum.
For a free brochure contact Parker Hannifin.
For more information contact:
Parker Hannifin Corp.
SSD Drives Division
9225 Forsyth Park Drive
Charlotte, NC 28273-3884
704-588-3246
www.ssddrives.com/usa
www.parker.com
