TECHNI Waterjet will be featuring the QUANTUM NXT Electric Servo Pump ESP66 Dual, and the TJ3000-X3 (5' x 10') waterjet cutting machine, the PAC 60 five-axis cutting head for taper elimination and 60° bevel cutting at Tulsa Industrial & Tool Show in Tulsa, OK, on April 20-21, 2016. The company's booth will be performing demonstrations throughout the entire show on the TJ3000-X3 premium range machine.
The QUANTUM Electric Servo Pump incorporates a servomotor directly enveloping a high load, precision ball screw. The ball screw directly houses the ceramic plungers, which reciprocate back and forth to create the pumping action, in much the same way as a hydraulic cylinder works on an intensifier pump.
"The TJ3000-X3 is built to the highest tolerances and incorporates linear scale feedback to ensure high accuracy. By mapping the entire cutting area with a laser-calibrated digital encoder, the motion system can deliver positional accuracy of 0.0005" (0.01 mm) and high cutting speeds of up to 1,000 IPM or 25 m/min," said a company spokesperson.
New Rotary-Axis Direct Drive Motor
Also on display will be the Rotary Axis, which is a direct drive motor assembly capable of accurately (+/- 0.1 degrees) positioning and contouring a workpiece under the cutting stream. The new Rotary Axis is available on all models of TECHNI waterjets including the TJ3000-X3 machine.
"The accuracy of the TECHNI Waterjet Rotary Axis makes it suited for precision applications such as medical components, while also powerful enough to rotate relatively large tubes (to 300 mm diameter) for architectural and fabrication applications," said the spokesperson The hollow bore will allow for bar feeding and automation applications up to 40 mm diameter.
- Manufactured from corrosion resistant materials
- 40 mm diameter through bore for barfeed applications
- Integrated with Softec software for easy use with a TECHNI Waterjet
- Capable of being retrofitted to most TECHNI Waterjet machines
- Accurate to (+/- 0.1 degree)
- High speed up to 120 RPM.
For more information contact:
TECHNI Waterjet
15301 W. 109th St.
Lenexa, KS 66219
1-888-TECHNI-3 (832-4643)
sales@techniwaterjet.com
www.techniwaterjet.com
Tulsa Industrial & Tool Show Booth FS301
