5-Axis Compact High Rail CNC Machining Center with Larger Work Envelope

At IMTS C.R. Onsrud introduced and demonstrated its new 5-axis Compact High Rail tailored to the high load and large work volume requirements of the aerospace, automotive, medical and defense industries.

"The design and development of this new machine was driven by customer feedback, allowing us to fulfill requirements of these demanding sectors," said Jeff Onsrud, Director of Sales & Business Development for C.R. Onsrud.

C.R. Onsrud offers these machines in two standard configurations. The F148CH is 84" x 144" x 53" (XYZ), overall length 200", overall width 322" and overall height 177". The F148CH W10 is 120" x 144" x 53" (XYZ), overall length 236", overall width 322" and overall height 177". Custom sizes are available.

The Compact High Rail Series features 15 HP, 24,000 RPM spindles (with 24 HP and 33 HP options); FANUC 31i or Osai Open control; 15 position tool rack (with optional larger capacity tool chains); vacuum hold down (with optional fixture plate or T-slot tables); and chip pan (with optional chip conveyor).

Additional options include retractable roof for easy material loading, inkjet part marking, auto tool measurement, robotics integration, continuous C-axis and linear scale feedback.

C.R. Onsrud is an American manufacturer of CNC machining centers. The company designs, builds and supports its CNC machinery that is used in a wide range of applications and industries.

For more information contact:

C.R. Onsrud

120 Technology Drive

P.O. Box 419

Troutman, NC 28166

800-638-8185 / 704-508-7000
