TAIYO KOKI Vertical Mate 85 from DMG MORI
TAIYO KOKI Vertical Mate 85 making a 24" deflector
Inspecting a part with the IM-800 Series
IM-8000 Series
Close-up of the IM-8000 Series
Guill Tool, provider of extrusion tooling, recently announced the purchase of a CNC grinder and a CT scanner.
The company's rheology lab measures the flow characteristics of plastics and rubber to better predict how the customer's material will flow through the extrusion dies before they are made. Together with the scanner, simulation reduces the number of physical reworks needed.
Sold by DMG MORI, the TAYIYO KOKI is a CNC vertical multiprocess machine grinding ID, OD and face by one-time chucking. The ATC unit stores up to six tools. Features of the wheel spindle include HSK-E100 single spindle and a two-position turret with indexing angle 0 and 22.5." An optional touch sensor for measuring ID, OD and face is available, as well as a scale feedback control for the X-axis. Control for the Z-axis is also available upon request. Additional features include a single point dresser (rotary dresser as an option) and a work spindle fixed-position stop. Vertical Mate 85 is suited for applications such as planetary gears, spindle housings and bevel gears.
In the job shop, Guill offers CNC grinding technology with full automation in lights-out mode as well as custom service for dies, stainless steel manufacturing and fabrication.
Capable of high-definition imaging, the IM-8000 Series Image Dimension Measurement System has triple the detection performance without sacrificing its simple operation, the company reported. With a 20-megapixel CMOS sensor and a new algorithm for stable edge detection, high accuracy measurement on up to 300 features within seconds is available. Newly developed, optional automated rotary fixture allows 360° multisurface measurement on diverse part sizes and shapes. Accurate and repeatable measurements are achieved with the "place and press" operation. The accurate and easy-to-use interface solves several measurement-related problems.
For more information contact:
Tom Baldock, Sales Manager, Extrusion
Guill Tool & Engineering
10 Pike Street
West Warwick, RI 02893
401-465-5526
tbaldock@guill.com
www.guill.com
