Ultrasonic Thickness Inspection



Verisurf Software uses the Renishaw RUP1 (REVO Ultrasonic Probe) to automate thickness measurement and reporting.

Verisurf Software, Inc. has announced support for the Renishaw RUP1 (REVO Ultrasonic Probe), providing an ultrasonic thickness probing solution to automate the measurement and reporting of thickness requirements.

Support for the RUP1 is featured in the Verisurf 2024 release. Leveraging the Dynamic Surface Points tool, Inspection Plans within Verisurf now incorporate ultrasonic thickness measurements. These measurements are stored and presented through a graphical balloon, providing recipients of the report with an easy-to-read thickness map associated with the inspected component. With the RUP1, thickness evaluation is possible for typical metal parts ranging from 1 mm (.039") to 20 mm (.787") in thickness, with an accuracy of .01 mm (.0004") on parallel surfaces and .100 mm (.0039") on wedged surfaces with an angle of up to 10°.

Verisurf Software operates Renishaw-equipped CNC CMMs through the Verisurf Device Interface (VDI), facilitating seamless communication with a wide range of 3D measurement devices. The VDI empowers customers to select their preferred devices while offering a standardized solution that supports design, tolerancing, validation, machining, assembly, measurement, inspection planning, reporting, analysis and reverse engineering.

"Verisurf has been a long-standing supporter of Renishaw-equipped CMMs and standalone Renishaw products, and our team remains dedicated to continually adding value through our software solutions, manufacturing expertise and engineering experience. Verisurf solutions are renowned for their user-friendliness, stability, flexibility, and intelligent workflows, which enhance efficiency, quality and throughput," stated Nick Merrell, Executive Vice President of Verisurf Software, Inc.

Verisurf measurement, reverse engineering and inspection software is built on a full-featured 3D CAD/CAM platform with intelligent Model-Based Definition (MBD). This helps ensure data integrity and enables users to perform metrology workflows in a seamless CAD environment while maintaining model-based digital continuity. Verisurf software is compatible with all CAD file formats, and the Verisurf Device Interface (VDI) communicates with all 3D measurement devices for universal compatibility.

For more information contact:

Verisurf Software, Inc.

4907 E Landon Dr.

Anaheim, CA 92807

888-713-7201 / 714-970-1683

sales@verisurf.com

www.verisurf.com
