Solution for Testing Dial and Digital Indicators

Mahr Inc. has expanded its OPTIMAR 100, a solution for testing dial and digital indicators, test indicators and dial comparators, with image processing for the automated testing of measuring equipment. A new upgrade kit now makes working with the measuring instrument safer and faster: a camera automatically records the indicated values of the test indicators and forwards them to a software for processing. "The automated procedure saves time and replaces the exhausting and error-prone reading by the operator," said a company spokesperson.

The hardware and software add-on package provides a cost-efficient way to equip existing measuring stations with OPTIMAR 100 for automated testing. The measuring system, including image processing, is also available as a complete package under the name "Precimar OPTIMAR 100 BV."

The upgrade kit incorporates a USB 3.0 camera for fast image processing, and stable daylight-independent LED illumination along with secure digital identification and reading of digits. The QMSOFT software controls the measuring device, evaluates the camera image of the scale or number display of the test object, compares the values with the high accuracy internal reference scale and automatically completes the process of calibrating the product under test. The software also makes it possible to create and store test certificates.

The operation of the OPTIMAR 100 with image processing speeds up and facilitates the monitoring of the indicators under test. "With the auto-recognition of the vision system, more test items and data points can be recorded faster than with conventional manual methods," said the spokesperson. Since this is a completely automated inspection system, the operator can be more productive in other operations while the OPTIMAR 100 automatically completes the calibration process.

For more information contact:

Mahr Inc.

1144 Eddy Street

Providence, RI 02905

800-343-2050 / 401-784-3100
