New Deepdish Series Vacuum Cups Improve Grip Performance

DESTACO, a global provider of precision movement, positioning and control solutions in industrial automation, has introduced its new Deepdish Series Vacuum Cups, which are designed to maximize grip performance on contoured and oily surfaces.

The vacuum cups feature an all new bell-shaped body design, available in three sizes, 65, 90 and 110 mm. Unique, molded-in gussets prevent the cup edges from rolling up on convex surfaces while the thin, pliable design and special inner tread pattern allow the cups to effectively adhere to flat, convex, concave, domed and oily surfaces for maximum grip performance.

"The addition of the Deepdish Series to our vacuum cup line instantly expands the number of applications and uses for our cups. These new cups establish a whole new standard of operational reliability, longevity and productivity for our customer's pick-and-place parts handling needs," stated Matt Girand, Vice President, Global Research, Development & Engineering of DESTACO. "We are constantly striving to innovate new ways to help manufacturers improve their production processes, and the addition of the Deepdish Vacuum Cups illustrates this commitment."

"Another key attribute that sets the new DESTACO Deepdish cups apart is the polyurethane materials-of-construction. Polyurethane provides enhanced wear-resistance when compared to rubber to promote longer service life and reduced maintenance. In addition, polyurethane will not leave any marks on handled objects and has enhanced elastic memory, even after hundreds of thousands of cycles. To top off this robust feature set, the vacuum cups have a durometer of 60 (PU60, translucent red in color). The 60 durometer makes it easier to pick up highly contoured panels, while also being capable of withstanding the elevated shear forces that are created by increased acceleration and deceleration rates," said a company spokesperson.

Mounting options include traditional 3/8" imperial NPT, 3/8" Metric-G and 1.25" square T-slot, along with a new lightweight plastic 3/8" Metric-G model. All mounts are interchangeable with existing standard mounts. Installation involves unscrewing the old mount and replacing it with a new one, at most a 10-second task.

For more information contact:


691 N. Squirrel Road, Suite 250

Auburn Hills, MI 48326

888-DESTACO (337-8226) / 248-836-6700
