CNC Offers Enhanced Software Features



ACU-RITE's MILLPWRG2 CNC control for vertical knee mills now has enhanced software features. New functions include a geometry calculator, tool plunge and G-code editing capabilities.

The MILLPWRG2 geometry calculator is used to construct point/line/arc entities, which can then be transferred to the part program. This MILLPWRG2 built-in calculator is capable of handling everything from simple arithmetic to complex trigonometry, geometry and RPM calculations. The numeric keypad resembles a standard calculator with keys for numbers zero through nine, four math function symbols (+, -, x and ö), a decimal point and a positive/negative sign (+/-).

The addition of the MILLPWRG2's G-code programs offers basic editing capabilities, as well as allowing the value of an existing G-code address to be changed. The values of the following addresses can be edited: F, I, J, K, L, M, N, O, P, S, T, X, Y and Z.

A tool step has been added to the MILLPWRG2 to support plunge angle (the angle at which the tool will enter the material). This tool step can call upon a specific tool number from the tool library and define plunge angle when ramping into a part pocket.

The programming on the MILLPWRG2 control is done via easy-to-understand plain language user prompts that are accompanied by 3D graphic "Help" forms that clearly describe each cycle step, creating an instinctive interface designed to maximize efficiency and increase production. Using simplified navigation that eliminates multiple menu screens, the MILLPWRG2 improves on its interface and functionality by maintaining the same programming language while incorporating an enhanced navigation system.

Additionally, the G2 offers standard features like USB, networking accessibility, solid model graphics and a new large 12.1" high-resolution display (1,024 x 768). Built on the HEIDENHAIN NC Kernel platform, the MILLPWRG2 features a 1 GHz processor with 2.5 GB of memory.

ACU-RITE products are represented and distributed through parent company HEIDENHAIN Corporation.

For more information contact:

HEIDENHAIN Corporation

333 E. State Parkway

Schaumburg, IL 60173-5337

847-490-1191

info@heidenhain.com

www.heidenhain.us
